Applications

Varnish is a common problem often seen in applications that use the new group II & III base oils. It’s a result of water problems, air problems, temperature fluctuations and oil degradation. This is often a problem in a variety of industrial applications like…
• Power generation (turbines)
• Steel, copper, aluminum (presses)
• Pulp and paper (paper machines)
• Plastic injection molding and blow molding
• Automotive and tires (stamping / forging / curing)
• Petrochemical (compressors)
• Aerospace (flight simulators)

Descriptions

Benefits

• Reduces the rate of additive consumption
• Reduces and prevents servo valve sticking
• Removes oxidation by-products
• Does not add water or other by-products to the system
• Operates at a wide range of oil temperatures
• Compatible with all mineral and phosphate ester fluids
• Operates on fluids containing more than 500 ppm of water
• Can be configured for applications with fluid volumes up to 36,000 liters (9,500 gallons)
• Due to its modular design, you can choose from a variety of housing lengths or combine multiple housings for a larger system


SPECIFICATIONS

Nominal Flow
• 1 l/min (0,26 GPM) per cartridge
By-pass Opening Pressure
• 5 bar (72,5 psi)
Pump Safety Valve
• 15 bar (217 psi)
Fluid Temperature
• 20° – 80° C (68° – 176° F)
Power Supply
• 10.00 / 254
Inlet Connection
• Depending on the pump, contact a Des-Case sales representative
Outlet Connection
• 1/2’’ BSPP female
System Seal
• FPM (Viton)
Fluid Compatibility
• Mineral oil, synthetic ester, phosphate esters (for other fluids, please contact us)
Dimensions
• Unit dependent, contact a Des-Case sales representative
Weight
• Unit dependent, contact a Des-Case sales representative



Element Specs
Cartridge Material
• Long Fiber Cellulose / Polypropylene
Apparent Dirt Holding Capacity
• 1.955 g (4,3 lb)
Water Absorption
• 2.6 liters (0.69 gal)
